15HP Solar Pump Inverters ac to ac DC 250V to DC 750V ac motor drive
EM15-SP series solar inverter is high-efficiency solar water pump controller, which with high MPPT efficiency, green environmental protection, economic and energy saving, widely use for agricultural irrigation, water supply system and etc.
Products Feature:
Energy consumption
Energy Consumption Comparison :Use the traditional energy will cause pollution,and in the cost of rising trend,the use of clean energy has use cost and environmental cost advantages.
Maintenance costs
Use and maintenance:The solar energy system life for up to 25 years,and low failure rate , Automatic operation ,
Don't need someone to watch,Maintenance personnel can be divided into many groups to patrol.
- The water level detection functions, which can support terminal /analog detection.
- PV power, PV current, pump flow rate and other operating parameters are accurately displayed.
- All series of products can realize the switching of AC power supply or PV power supply to meet the 24-hour work;
- Accurate and fast MPPT algorithm tracking PV battery maximum power point, ensure 99% solar power tracking efficiency.
- Support for basic function of inverters, such as terminal control start and stop, RS485 communication, which can remote operation and monitoring.
EM15-SP3 Description | d75 | 1d5 | 2d2 | 004 | 5d5 | 7d5 | 011 | 015 | 018 | 022 | 030 | 037 | 045 |
| 055 | 075 | 090 | 110 | 132 | 160 | 200 | 220 | 250 | 280 | 315 | 355 | 400 |
| DC input (+, -) |
| Rated power/KW | 0.75 | 1.5 | 2.2 | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 |
| 55 | 75 | 90 | 110 | 132 | 160 | 200 | 220 | 250 | 280 | 315 | 355 | 400 |
| Min. DC voltage/V | 280 |
| Max.DC voltage/V | 750 |
| Recommended MPPT range /V | 350~750 |
| AC output(U, V, W) |
| Output current | 2.1 | 3.8 | 5.1 | 9 | 13 | 17 | 25 | 32 | 37 | 45 | 60 | 75 | 91 |
| 112 | 150 | 176 | 210 | 253 | 304 | 377 | 426 | 465 | 520 | 585 | 650 | 725 |
| Output frequency | 0~50/60Hz |
| Power factor | >0.99 |
| Communication mode | RS485 communication |
| Protection class | IP20 |
| Ambient temperature | -10℃~ +40℃(ambient temperation at 40℃~50℃,please keep derated use) |
| Storage temperature | -20℃~ +60℃ |
| Humidity | Smaller than 95%RH, non-condensation |
| Cooling | Forced Air cooling |
| Altitude | Lower than 1000 m |
| Humidity | Less than 95%RH, without condensing |
| Vibration | Less than 5.9 m/s2 (0.6 g) |
Q&A
Who are we?
We are based in Guangdong, China, start from 2017,sell to Domestic Market(50.00%),Southeast Asia(12.00%),Eastern Europe(12.00%),South America(5.00%),Eastern Asia(3.00%),Northern Europe(3.00%),Oceania(3.00%),Southern Europe(3.00%),North America(2.00%),Western Europe(2.00%),Mid East(2.00%),Africa(1.00%),South Asia(1.00%),Central America(1.00%). There are total about 51-100 people in our office.
What's about your delivery time?
All type we have stock,after we receive payment,we will send you within two days.
What is your production capacity?
Each product has different production capacity, we can talk details by email.
What kind of product quality your factory offer?
We offer most competitive prices with best quality
Product Tags:
|
|
22A 15HP Solar Pump Inverters DC To AC Motor Drive Images
|
